IT8212 Setup Utility (C)Copyright 2002-2004 ITE, Inc.
[ Define RAID Menu ]
Array No Array Mode Drive No Size(MB) Status
Array 0 ---- ---- ----- -----
Array 1 ---- ---- ----- -----
Array 2 ---- ---- ----- -----
Array 3 ---- ---- ----- -----
∗∗
∗∗
∗ : Capacity (GB)
♦ ♦
♦ ♦
♦ : Bootable Array
[
↑↑
↑↑
↑] Up [
↓↓
↓↓
↓] Down [Space] Boot Array [Enter] Select [ESC] Exit
Defining a RAID arrayDefining a RAID array
Defining a RAID arrayDefining a RAID array
Defining a RAID array
This option allows you to define the RAID set(s).
To define a RAID set(s):
1. Press <2> from utility main menu. The following screen appears.
2. Press the up/down arrow keys or the space bar to select a RAID set
you want to define, then press <Enter>.
IT8212 Setup Utility (C)Copyright 2002-2004 ITE, Inc.
[ Define RAID Sub-Menu ]
∗∗
∗∗
∗ : Capacity (GB)
[
↑↑
↑↑
↑] Up [
↓↓
↓↓
↓] Down [Space] Change Option [Ctrl-Y] Save [ESC] Exit
Channel
ID Drive Name Size(MB) Assignment
Pri/D0 XXXXXXXXXXXXXX XXXXXX Y
Pri/D1 XXXXXXXXXXXXXX XXXXXX Y
Sec/D0 XXXXXXXXXXXXXX XXXXXX Y
Sec/D1 XXXXXXXXXXXXXX XXXXXX Y
[ Drive Assignments]
Array No Array Mode Drive No Status
Array 0 Stripe 4 Functional
Block Size: 64KB
3. Press the up/down arrow keys to move through the RAID set values.
4. Press the Space bar to adjust the RAID set values.
