Asus P5RD2-VM User Manual

ASUS P5RD2-VM 1-7
1.5.3 Motherboard layout
CR2032 3V
Lithium Cell
CMOS Power
CD
Super
I/O
4M
BIOS
LPC
ATX12V
FLOPPY
AAFP
DDR2 DIMM1 (64 bit,240-pin module)
SB_PWR
USB78
USB56
PCI1
ATI
RC410
ULI
M157
5
CHA_FAN2
CPU_FAN
PRI_IDE
EATXPWR
SPDIF_OUT
RTL8111B
PS/2KBMS
T: Mouse
B: Keyboard
Below:Mic In
Center:Line
Out
Top:Line In
USB12
LAN_USB34
PCIEX1_1
PCIEX16
COM1
PARALLEL PORT
VGA1
®
P5RD2-VM
SATA1
SEC_IDE
DDR2 DIMM2 (64 bit,240-pin module)
PCI2
KBPWR
AUX
TV_C
USBPW34 USBPW12
AD1986A
24.3cm (9.6in)
21.8cm (8.6in)
LGA775
CHASSIS
SATA2
SATA3
SATA4
CLRTC
USBPW56
USBPW78
PANEL
CHA_FAN1

Asus P5RD2-VM Specifications

General

Number of memory slots	2
Maximum internal memory	2 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
CPU fan connector	Yes
USB 2.0 connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	1
Dimensions (WxDxH)	244 x 218 mm
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Bundled software	ASUS PC Probe II ASUS LiveUpdate Utility Anti-virus software
Networking features	10/100/1000 Mbit/s LAN
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	218 mm
Width	244 mm
