Asus P7P55D-E LX User Manual

ix
P7P55D-E LX specications summary
(continued on the next page)
CPU
LGA1156 socket for Intel
®
Core™ i7 / Core™ i5 /
Core™ i3 processors
Supports Intel
®
Turbo Boost Technology
* Refer to www.asus.com for Intel CPU support list
Chipset
Intel
®
P55 Express Chipset
Memory
4 x DIMM, max. 16GB, DDR3 2200(O.C.)* / 1600 / 1333 /
1066 MHz, non-ECC, un-buffered memory
Dual channel memory architecture
Supports Intel
®
Extreme Memory Profile (XMP)
* Hyper DIMM support is subject to the physical
characteristics of individual CPUs. Some hyper DIMMs
only support one DIMM per channel. Please refer to
Memory QVL for details.
** Refer to www.asus.com or this user manual for the
Memory QVL (Qualified Vendors Lists)
Expansion Slots
1 x PCI Express 2.0 x 16 slot
4 x PCI Express 2.0 x1 slots (2.5GT/s)
2 x PCI slots
Storage Intel
®
P55 Express Chipset:
- 6 x SATA 3.0 Gb/s ports
- Intel
®
Matrix Storage Technology supporting SATA
RAID 0,1, 5, and 10
JMicron
®
JMB361 SATA & PATA controller
- 1 x Ultra DMA 133/100/66 for up to 2 PATA devices
- 1 x eSATA 3.0 Gb/s port (SATA on-the-go)
Marvell
®
PCIe SATA 6Gb/s controller:
- 2 x SATA 6.0 Gb/s ports (gray)
LAN
Realtek
®
8112L Gigabit LAN controller featuring AI NET2
USB NEC USB 3.0 controller:
- 2 x USB 3.0 ports (blue; at back panel)
Intel
®
P55 Express Chipset:
- 12 x USB 2.0 ports (6 ports at mid-board, 6 ports at
back panel)
Audio
VIA
®
VT1708S 8-channel High Definition Audio CODEC
- Supports Jack-Detection, Multi-streaming,
and Front Panel Jack-Retasking
- Optical S/PDIF out port at back I/O

Asus P7P55D-E LX Specifications

General

Form Factor	ATX
Chipset	Intel P55
CPU Socket	LGA 1156
Memory Type	DDR3
Maximum Memory	16GB
PCI Express x16 Slots	1
PCI Express x1 Slots	2
PCI Slots	3
SATA 3Gb/s Ports	6
SATA 6Gb/s Ports	2
USB 2.0 Ports	12
LAN	Realtek 8112L Gigabit LAN controller
Memory Slots	4
Memory Standard	DDR3 2200(O.C.)/1600/1333/1066
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
