Asus P8H61-M LX3 PLUS R2.0 User Manual

ix
P8H61-M LX3 R2.0 Series specications summary
ASUS unique features ASUS Anti-Surge Protection
ASUS UEFI BIOS featuring friendly graphics user interface
ASUS AI Suite II
ASUS Fan Xpert
ASUS Q-Fan 2
ASUS Network iControl* featuring instant network bandwidth
domination for top network program in use
ASUS AI Charger
ASUS WebStorage
ASUS CrashFree BIOS 3
ASUS EZ Flash 2
ASUS MyLogo 2™
* The ASUS Network iControl feature does not support
Windows
®
XP/Vista operating systems.
Rear panel ports 1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
1 x D-Sub port
1 x LAN (RJ-45) port
4 x USB 2.0/1.1 ports
3 x Audio jacks
Internal connectors/
jumpers
3 x USB 2.0/1.1 connectors support additional 6 USB 2.0/1.1
ports
4 x SATA 3.0 Gb/s connectors
1 x 4-pin CPU fan connector
1 x 4-pin chassis fan connector
1 x Front panel audio connector
1 x System panel connector
1 x Speaker connector
1 x 24-pin ATX power connector
1 x 4-pin ATX 12V power connector
1 x Clear CMOS jumper
BIOS features 64 Mb Flash ROM, UEFI BIOS, PnP, DMI v2.0, WfM 2.0, ACPI
v2.0a, SM BIOS v2.7, SLP 3.0, EUP-ready, Multi-language
BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, F12
PrintScreen function, F3 Shortcut function, and ASUS DRAM
SPD (Serial Presence Detect) memory information
Manageability
WOL, PXE, PME Wake Up
Accessories 2 x Serial ATA 3.0Gb/s cables
1 x I/O shield
1 x User Manual
1 x Support DVD
Support DVD Drivers
ASUS utilities
ASUS Update
Anti-virus software (OEM version)
Form factor
MicroATX form factor: 8.9 in x 6.8 in (22.6 cm x 17.3 cm)
* Specications are subject to change without notice.

Asus P8H61-M LX3 PLUS R2.0 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2000, 2133, 2200 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel® Celeron®
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
DVI-D ports quantity	00
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II
On-board graphics card	No
Parallel processing technology support	Not supported
PCI Express slots version	2.0, 3.0
Cables included	SATA
LAN controller	Realtek RTL8111F
Networking features	10/100/1000 Mb/s
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	172 mm
Width	226 mm
