Asus P8H61-M LX3 PLUS R2.0 User Manual

viii
P8H61-M LX3 R2.0 Series specications summary
(continued on the next page)
CPU LGA1155 socket for Intel
®
3rd/2nd Generation Core™ i7 / Core™
i5 / Core™ i3 / Pentium
®
/ Celeron
®
processors
Supports Intel 22nm CPU
Supports Intel
®
Turbo Boost Technology 2.0
* The Intel
®
Turbo Boost Technology 2.0 support depends on the
CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H61 Express Chipset
Memory 2 x DIMMs, max. 16GB, DDR3 2200 (O.C.) / 2133 (O.C.) / 2000
(O.C.) / 1866 (O.C.) / 1600 / 1333 / 1066 MHz, non-ECC, un-
buffered memory
Dual-channel memory architecture
* DDR3 1600 MHz and higher memory frequency is supported by
Intel
®
3rd generation processors.
** Refer to www.asus.com for the latest Memory QVL (Qualied
Vendors List).
*** When you install a total memory of 4GB capacity or more,
Windows
®
32-bit operating system may only recognize less than
3GB. We recommend a maximum of 3GB system memory if you
are using a Windows
®
32-bit operating system.
Expansion slots 1 x PCI Express 3.0*/2.0 x16 slot with latch
2 x PCI Express 2.0 x1 slots
* PCIe 3.0 speed is supported by Intel
®
3rd generation Core™
processors.
Graphics Supports D-Sub with max. resolution of 2048 x 1536 @75Hz
Max. UMA Memory: 1748MB
Storage
Intel
®
H61 Express Chipset:
- 4 x Serial ATA 3.0 Gb/s connectors
LAN
Realtek
®
8111F PCIe Gigabit LAN controller
Audio VIA
®
VT1708S 8-channel* High Denition Audio CODEC
- Supports Multi-Streaming
* Use a chassis with HD audio module in the front panel to
support an 8-channel audio output.
USB 10 x USB 2.0/1.1 ports (6 ports at the mid-board, 4 ports at the back
panel)
Other features 100% All High-quality Conductive Polymer Capacitors
(P8H61-M LX3 PLUS R2.0 only)

Asus P8H61-M LX3 PLUS R2.0 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2000, 2133, 2200 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel® Celeron®
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
DVI-D ports quantity	00
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II
On-board graphics card	No
Parallel processing technology support	Not supported
PCI Express slots version	2.0, 3.0
Cables included	SATA
LAN controller	Realtek RTL8111F
Networking features	10/100/1000 Mb/s
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	172 mm
Width	226 mm
