2-2 Chapter2:Setup
2.2 Adjusting the monitor
• Foroptimalviewing,werecommendthatyoulookatthefullfaceofthe
monitor,thenadjustthemonitortotheanglethatismostcomfortable
for you.
• Holdthestandtopreventthemonitorfromfallingwhenyouchangeits
angle.
• Youcanadjustthemonitor’sanglefrom+20˚to-5˚anditallows60˚
swiveladjustmentfromeitherleftorright.Youcanalsoadjustthe
monitor’sheightwithin+/-12cm.


12cm
-5° ~ +20°
60°
0°
60°
Pivoting the monitor
1. Liftthemonitortothehighestposition.
2. Tiltthemonitortoitsmaximumangle.
3. Pivotthemonitorclockwisetotheangleyouneed.
2



1


-5° ~ +20°
3
Itisnormalthatthemonitorslightlyshakeswhileyouadjusttheviewing
angle.
