Asus PB328Q User Manual

2-2 Chapter 2: Setup
2.2 Adjusting the monitor
• For optimal viewing, we recommend that you look at the full face of the
monitor, then adjust the monitor to the angle that is most comfortable for you.
• Hold the stand to prevent the monitor from falling when you change its angle.
• You can adjust the monitor’s angle from +25˚ to -5˚, and it allows 60˚ swivel
adjustment from either left or right. You can also adjust the monitor’s height
within +/- 150 mm.
-5° ~ +25°
60°
0°
60°
150mm

1. Lift the monitor to the highest position.
2. Tilt the monitor to its maximum angle.
3. Pivot the monitor clockwise to the angle you need.
-5° ~ +25°
It is normal that the monitor slightly shakes while you adjust the viewing angle.
(Tilt) (Swivel) (Height adjustment)

Asus PB328Q Specifications

General

3D	-
Panel type	VA
Color depth	12 bit
Pixel pitch	0.277 x 0.277 mm
Aspect ratio	16:9
Screen shape	Flat
Display surface	Matt
Display diagonal	32 \
Vertical scan range	49 - 76 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	398.52 mm
Contrast ratio (dynamic)	100000000:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	708.48 mm
Digital horizontal frequency	29 - 130 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	2560 x 1440
HDCP	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB Type-A downstream ports quantity	4
RMS rated power	6 W
Number of speakers	2
Certification	Energy Star, BSMI, CB, CCC, CE, CU, EPEAT (Gold), ErP, FCC, ISO-9241-307, J-MOSS, KCC, PSE, RoHS, Taiwan Green Mark, TCO6.0, UL/cUL, VCCI, WEEE, WHQL (Windows 8, Windows 7), RCM, Ukraine, KC , eStandby
Product color	Black
Pivot angle	0 - 90 °
Tilt angle range	-5 - 25 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A+ to F
Power consumption (off)	0 W
Annual energy consumption	52 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	32.36 W
Sustainability certificates	EPEAT Gold, ENERGY STAR
Package depth	350 mm
Package width	847 mm
Package height	552 mm
Package weight	16500 g
Cables included	Audio (3.5mm), DisplayPort, DVI, HDMI, USB, VGA
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	242 mm
Width (with stand)	735 mm
Height (with stand)	625 mm
Weight (with stand)	11800 g
Depth (without stand)	66.85 mm
Width (without stand)	734.4 mm
Height (without stand)	431 mm
Weight (without stand)	- g
