3-36 Chapter 3: BIOS Setup
3.6.7 Hardware Monitor
Voltage Monitor
CPU Voltage; CPU PLL Voltage; QPI/DRAM Voltage; IOH Voltage;
IOH PCIE Voltage; ICH Voltage; ICH PCIE Voltage; DRAM Bus Voltage;
3.3V Voltage; 5V Voltage; 12V Voltage
The onboard hardware monitor automatically detects the voltage output
through the onboard voltage regulators.
Temperature Monitor
CPU Temperature; MB Temperature; IOH Temperature; ICH Temperature;
OPT TEMP 1/2/3 [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the CPU,
IOH/ICH, motherboard, power, and the assigned devices temperatures.
Select [Ignored] if you do not wish to display the detected temperatures.
IOH/ICH overheat protection [100ºC]
The system automatically shuts down when the IOH/ICH is heated over the
set temperature to protect it from damage.
Configuration options: [Disabled] [70ºC] [80ºC] [90ºC] [100ºC][100ºC]
OPT TEMP1/2/3 overheat protection [90ºC]
Allows you to set the temperature over which the system automatically shuts
down when any of the thermal sensor cables connected to the motherboard
detects device overheat to protect the device from damage.
Configuration options: [Disabled] [70ºC] [80ºC] [90ºC] [100ºC][100ºC]
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
