32
ROG GR8
Upgrading memory modules
Your ROG GR8 comes with two SO-DIMM memory slots that allow
you to install up to two 8 GB DDR3L 204-pin SO-DIMMs for a
maximum of 16 GB memory.
IMPORTANT! You can only install DDR3L (1.35V Low Voltage) 204-pin
SO-DIMM to the ROG GR8’s DIMM slots.
NOTE: Refer to http://www.asus.com for the list of compatible
DIMMs.
To install or upgrade the memory modules:
1. Turn o your ROG GR8.
2. Disconnect all cables and peripherals.
3. Place the ROG GR8 on its side on a stable and at surface.
4. Move down the latch at the rear panel to unlock the side cover.
NOTE: Before you remove the side cover, ensure that the UNLOCK
label on the latch is visible.
