Asus ROG GR8 - Page 38

38
ROG GR8
6. Remove the four screws that secures the 2.5-inch HDD/SSD
extension bay.
7. Using the ap, pull the extension bay to remove it from the
chassis.
ap
5. Slide the side cover towards the rear to detach it from the
chassis then gently lift to remove it from the chassis.
