2-14
Chapter 2: Basic Installation
Chapter 2
2.1.10 Wi-Fi antenna installation
Installing the ASUS 2x2 dual band W-Fi antenna
Connect the bundled ASUS 2x2 dual band Wi-Fi antenna connector to the Wi-Fi ports at the
back of the chassis.
• Ensure that the ASUS 2x2 dual band Wi-Fi antenna is securely installed to the Wi-Fi
ports.
• Ensure that the antenna is at least 20 cm away from all persons.
The illustration above is for reference only. The I/O port layout may vary with models, but
the Wi-Fi antenna installation procedure is the same for all models.
