3-1
ASUS LCD Monitor XG27VQ Series
• The VESA wall mount kit (100 x 100 mm) is purchased separately.
• Use only the UL Listed Wall Mount Bracket with minimum weight/load
22.7kg (Screw size: M4 x 15 mm).
2.2 Adjusting the Monitor
• For optimal viewing, we recommend that you look at the full face
of the monitor, then adjust the monitor to the angle that is most
comfortable for you.
• Hold the stand to prevent the monitor from falling while changing its
angle.
• The recommended adjusting angle is +20˚ to -5˚ (for tilt)/+50˚ to -50˚
(for swiveling), and adjustable height is 100 mm.
50°
50°
100 mm
• It is normal that the monitor slightly shakes while you adjust the viewing angle.
