Asus ROG STRIX XG27VQ User Manual

3-7
ASUS LCD Monitor XG27VQ Series
MyFavorite
System Setup
Input Select
Color
Blue Light Filter
MOVE/ENTER
BACK
EXIT
Power Key Lock
All Reset
GameVisual
Racing Mode Aura Off
ROG Strix XG27VQ
DisplayPort 1920x1080@ 144Hz
(Page 2/2)
• LIGHT IN MOTION: Set the red light intensity level on the base
from Level 1 to Level 3. To turn off the red light, set Level 0.
• Aura RGB: Set the Aura RGB light pattern on the rear of the
monitor. Available options: Rainbow, Color Cycle, Static,
Breathing, Strobing, and Off.
• For Aura RGB patterns, such as Static, Breathing, and Strobing you can set your
preferred color. The color options include red (R), green (G), blue (B), cyan (C),
magenta (M), and yellow (Y).
• Sound:
• Volume: Adjust the volume level from 0 to 100.
• Mute: Check to mute the volume.
• OSD Setup: Adjust the OSD Timeout, DDC/CI, and Transparency
of the OSD screen.
• Language: Select the OSD language.
• Information: Display the monitor information.
• Key Lock: Pressing down the ( ) button for more than ve
seconds to activate or deactivate the key lock function.
• Power Indicator: Turn the power LED indicator on/off.
• Power Key Lock: Disable/Enable the power key.
• All Reset: Select YES to revert all settings to the factory default
mode.

Asus ROG STRIX XG27VQ Specifications

General

3D	No
Panel type	VA
Pixel pitch	0.311 x 0.311 mm
Display diagonal	27 \
Screen curvature	1800 mm
Display technology	LED
Native aspect ratio	16:9
Supported video modes	480p, 576p, 720p, 1080p
Screen curvature rating	1800R
Viewable size, vertical	336.312 mm
Contrast ratio (dynamic)	100000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	595.303 mm
Digital vertical frequency	48 - 144 Hz
Digital horizontal frequency	55.3 - 162 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 832 x 624, 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 960, 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
No flickering	Yes
Headphone connectivity	3.5 mm
VGA (D-Sub) ports quantity	0
Feet color	Black/Red
Certification	BSMI, CB, CCC, CEL , FCC, J-MOSS, UkrSEPRO, UL/cUL, VCCI, WHQL, TUV , eStandby, CU(EAC), KC(EK)-SDoC, MSIP(KCC), CE(RCM)GEMS
Product color	Black, Red
Market positioning	Gaming
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Number of OSD languages	21
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FRE, HUN, IND, ITA, JPN, KOR, PER, POL, POR, RUM, RUS, THA, TUR
AC input voltage	110 - 220 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.5 W
Power consumption (standby)	- W
Power consumption (typical)	50 W
Package depth	268 mm
Package width	752 mm
Package height	560 mm
Package weight	9950 g
Cables included	AC
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	268.62 mm
Height (with stand)	423.91 mm
Weight (with stand)	6900 g
Depth (without stand)	109 mm
Width (without stand)	619.64 mm
Height (without stand)	371.12 mm
Weight (without stand)	- g
