3-14
Chapter 3: General Instruction
CEA Timing
Resolution
H Freq
(KHz)
V Freq
(Hz)
DCLK
(MHz)
HDMI
DP/
Type-C
640x480p-60 Hz 31.46 59.94 25.17 V V
720x480p-60 Hz 31.46 59.94 27 V V
720x480p-60 Hz 31.46 59.94 27 V V
1280x720p-60 Hz 45 60 74.25 V V
1920x1080i-60 Hz 33.75 60 74.25 V V
1440x480p-60 Hz 31.46 59.94 54 N/A V
1440x480p-60 Hz 31.46 59.94 54 N/A V
1920x1080p-60 Hz 67.5 60 148.5 V V
720x576p-50 Hz 31.25 50 27 V N/A
1280x720p-50 Hz 37.5 50 74.25 V V
1920x1080i-50 Hz 28.12 50 74.25 V N/A
1440x576p-50 Hz 31.25 50 54 N/A V
1440x576p-50 Hz 31.25 50 54 N/A V
1920x1080p-50 Hz 56.25 50 148.5 V V
1920x1080p-120 Hz 135 120 297 V N/A
1920x1080p-100 Hz 112.5 100 297 V N/A
2560x1080p-50 Hz 56.25 50 185.62 N/A V
2560x1080p-60 Hz 66 60 198 V V
2560x1080p-100 Hz 125 100 371.25 N/A V
2560x1080p-120 Hz 150 120 495 N/A V
3840x2160p-24 Hz 54 24 297 N/A V
3840x2160p-25 Hz 56.25 25 297 N/A V
3840x2160p-30 Hz 67.5 30 297 N/A V
3840x2160p-50 Hz 112.5 50 594 V N/A
3840x2160p-60 Hz 135 60 594 V V
PxP Supported Timing
Resolution
H Freq
(KHz)
V Freq
(Hz)
DCLK
(MHz)
HDMI
DP/
Type-C
1280x1440-60Hz (2560*1440) 88.77 59.94 120.72 V N/A
1720x1440-60Hz (3440*1440) 88.76 59.93 166.88 V N/A
1920x1600-60Hz (3840*1600) 98.66 59.94 197.32 V N/A
1920x2160-60Hz (3840*2160) 133.29 59.98 277.25 V N/A
