Asus ROG STRIX XG43VQ User Manual

3-10 Chapter 3: General Instruction
• Key Lock: Disable all key functions. Pressing the down button for
more than five seconds to disable key lock function.
• Power Indicator: Turn the power LED indicator on/off.
• Power Key Lock: To disable / enable power key
• All Reset: Selects “Yes” to revert all settings to the factory default
mode.
8. MyFavorite
Load/Save all settings on the monitor.
GameVisual
Color
Input Select
System Setup
MyFavorite
MOVE/ENTER
BACK
Setting 1
Setting 2
DisplayPort 3840x1080@ 144Hz
Racing Mode
ROG Strix XG43V HDR OFF
EXIT
GamePlus
PBP Setting
+

Asus ROG STRIX XG43VQ Specifications

General

Panel Size	43.4” W (110.23 cm)
Max. Resolution	3840 x 1200
Brightness (Typ.)	450 nits (typical)
Intrinsic Contrast Ratio (Typ.)	3000:1
Viewing Angle (CR>10)	178°(V) /178°(H)
Display Colors	1.07B (8bit+2FRC)
PBP	Yes
Response Time	4 ms (G To G )
Sound from HDMI	Yes
Earphone	Yes
Speaker	5 W x 2
HDMI input	HDMI2.0 x 2
DisplayPort input	Yes
USB3.0 Port	Upstream x1, Downstream x2 (USB port without power charger when upstream no link)
Power On Consumption	< 47 W* (Measuring a screen brightness of 200 nits without audio/ USB/ Card reader connection)
Power saving mode	< 0.5W
Power off mode	< 0.5W
Voltage Rating	Adapter 20Vdc, 7.5A
Chassis Colors	Black
Tilt	-5° ~ 20°
Temperature (operating)	0°C ~ 40°C

Weight and Dimensions

Phys. Dimension with stand (WxHxD)	1057.12 x 517.46 x 309.03 mm
Phys. Dimension without stand (WxHxD)	1057.12 x 361.26 x 158.66 mm
Box Dimension (WxHxD)	1152 x 456 x 370 mm
Net Weight with Stand (Esti.)	12.0 kg
Net Weight without Stand (Esti.)	8.3kg
Gross Weight (Esti.)	TBD kg
