2-4 Chapter 2: Setup
2.4 Detaching the arm (for VESA wall
mount)
The detachable arm of this monitor is specially designed for VESA wall mount.
To detach the arm:
1. Have the front of the monitor face down on a table.
2. Use a screwdriver to remove the covers on where the monitor and the arm
meet.
3. Loosen the four screws on the back of the monitor and remove the arm/base.
4. Fasten the wall mount screws.
1 2 3 4 5
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
• The VESA wall mount kit (100 x 100 mm) is purchased separately.
• Use only the UL Listed Wall Mount Bracket with minimum weight/load
22.7kg (Screw size: M4 x 10 mm)
