Asus ROG SWIFT PG32UCDM - Chapter 2: Setup; 2.1 Attaching the Arm;Base

2-1ASUS PG32UCDM Series OLED Monitor
2.1 Attaching the arm/base
To assemble the monitor base:
1. Open the box as illustrated. (Figure 1)
2. Insert the base into the arm. Fix the base to the arm by fastening the bundled
screw. (Figure 2)
3. Attach the arm into the monitor. (Figure 3)
4. Hold the stand and lift the monitor carefully, then place it on a at surface.
(Figure 4)
1
2
1
2
(Figure 2)
(Figure 1)
(Figure 3)(Figure 4)
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
Base screw size: M5 x 25 mm.
