ASUS RS720A-E12 Series
1-9
1.6 Internal features
The barebone server includes the basic components as shown.
WARNING
HAZARDOUS MOVING PARTS
KEEP FINGERS AND OTHER BODY PARTS AWAY
A protection film is pre-attached to the front cover before shipping. Please remove the
protection film before turning on the system for proper heat dissipation.
1. Riser card bracket
2. OCP module (hidden,
optional)
3. Redundant power supply
(hidden)
4. PCIe riser card (hidden)
5. ASUS K14PP-D24 Server
Board
6. System fans
7. NVMe/SATA/SAS back panel
8. Front USB Board
9. Asset tag (hidden)
10. Front panel (hidden)
11. 24 x 2.5” storage device trays
Standard model

Asus RS720A-E12-RS24U Specifications

General

Form Factor	2U
Storage	24 x 2.5"
Networking	Dual 10GbE LAN
Power Supply	2 x 800W redundant power supplies
Operating System Support	Windows Server, Linux
Memory Slots	24 DIMM slots
