Asus RT-AC66U User Manual

6
1 Getting to know your wireless
router
NOTES:
• If any of the items are damaged or missing, contact ASUS for
technical inquiries and support, Refer to the ASUS Support Hotline
list at the back of this user manual.
• Keep the original packaging material in case you would need future
warranty services such as repair or replacement.
RT-AC66U Wireless Router Network cable (RJ-45)
Power adapter Quick Start Guide
Support CD (Manual, utility software) Warranty card
Stand
1.1 Welcome!
Thank you for purchasing an ASUS RT-AC66U Wireless Router!
The ultra-thin and stylish RT-AC66U features a 2.4GHz and 5GHz
dual bands for an unmatched concurrent wireless HD streaming;
SMB server, UPnP AV server, and FTP server for 24/7 le sharing;
a capability to handle 300,000 sessions; and the ASUS Green
Network Technology, which provides up to 70% power-saving
solution.
1.2 Package contents

Asus RT-AC66U Specifications

General

VPN support	IPSec, PPTP, L2TP, PPTP
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi standards	802.11a, 802.11b, 802.11g
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	1300 Mbit/s
Rack mounting	-
Frequency band	2.4 & 5 GHz
xDSL connection	No
USB ports quantity	2
WLAN data transfer rates supported	1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, 450, 1300 Mbit/s
Ethernet LAN (RJ-45) ports	4
Supported network protocols	IPv4, IPv6
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Antennas quantity	3
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
LED indicators	LAN, Power, USB, WAN
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	148.8 mm
Width	207 mm
Height	35.5 mm
Weight	450 g
