5. Press <F10> to save your changes, exit the BIOS Setup program, and reboot your
system. The EFI Shell prompt screen displays.
6. Key in fs0: to access the USB drive where the update les are located.
Navigate to the directory (TPM_FU_5.63\Tools\UEFI\Bin\x64) where the update les
are located, key in dir and press <Enter> to display the content.
EFI Shell version 2.60 [5.13]
Current running mode 1.1.2
Device mapping table
fs0 :Removable HardDisk - Alias hd6c0b blk0
PciRoot(0X0)/Pci(0x14,0x0)/USB(0x2,0x0)/HD(1, MBR, 0x25474627,0x3F, 0x777
FC1)
blk0 :Removable HardDisk - Alias hd6c0b fs0
PciRoot(0x0)/Pci(0x14,0x0)/USB(0x2,0x0)/HD(1, MBR, 0x25474627,0x3F. 0x777
FC1)
blkl :Removable BlockDevice - Alias (null)
PciRoot(0x0)/Pci(0x14,0X0)/USB(0X2,0x0)
Press ESC in 1 seconds to skip startup.nsh, any other key to connue.
Shell>
EFI Shell version 2.60 [5.13]
Current running mode 1.1.2
Device mapping table
fs0 :Removable HardDisk - Alias hd6c0b blk0
PciRoot(0X0)/Pci(0x14,0x0)/USB(0x2,0x0)/HD(1, MBR, 0x25474627,0x3F, 0x777
FC1)
blk0 :Removable HardDisk - Alias hd6c0b fs0
PciRoot(0x0)/Pci(0x14,0x0)/USB(0x2,0x0)/HD(1, MBR, 0x25474627,0x3F. 0x777
FC1)
blkl :Removable BlockDevice - Alias (null)
PciRoot(0x0)/Pci(0x14,0X0)/USB(0X2,0x0)
Press ESC in 1 seconds to skip startup.nsh, any other key to connue.
Shell> fs0:
fs0:\TPM_FU_5.63\Tools\UEFI\Bin\x64> DIR

Asus TPM-M R2.0 Specifications

General

Form factor	Internal
Plug and Play	Yes
Product color	Black
SmartCard slot	No
Security algorithms	-
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Quantity per pack	1 pc(s)

Weight and Dimensions

Width	15 mm
Height	25 mm
