19" LCD Color Monitor ASUS VB191T&S
33
6.3 Audio Board
715G2098-1ASU
GND
+
C209
1uF
+
C208
470uF/16V
+
C201
470uF/16V
+
C205
470uF/16V
1
Audio
A
11Wednesday , January 10, 2007
Tit le
Size Document Number Rev
Date: Sheet
of
C211
100pF
CN202
CONN
2
4
6
8
10
12
14
1
3
5
7
9
11
13
U201
E-TDA7496L
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
GND
GND
GND
INL
VAROUT_L
VOLUME
VAROUT_R
NC
INR
SVR
STBY
MUTE
GND
OUTR
VS
VS
OUTL
GND
GND
GND
715G2098-1ASU
GND
R207
1K 1/10W
R202
200 KOHM +-5% 1/10W
C213
0.1uF 50V
R212
220K 1/10W
C206
0.47uF/25V
CN204
NC
1
2
3
CN201
PHONEJACK
1
2
3
4
5
12V
GND R211
20 KOHM +-5% 1/10W
VOLUME
R208
1K 1/10W
+12V
+12V
C204 0.47uF/25V
C214
NC
OUT_R
C203
0.1uF 50V
R210
20 KOHM +-5% 1/10W
GND
+
C210
1uF
GND GND
GND
OUT_L
R203 18K 1/10W
STANDBY
+
C202
470uF/16V
GND GND
R201
18K 1/10W
MUTE
CONN
3
2
1
4
+
C207
470uF/16V
C212
100pF
