19" LCD Color Monitor ASUS VB191T&S
46
2.) W / LED, No Backlight
Check CN902 pin4, 5 = 12V
NG
OK
Check adapter or MB
Check ON/OFF signal
Check Interface board
NG
OK
Check IC801 PIN12=12V
NG
OK
Change Q808
Check IC801 PIN10, 9 have the output of square wave at short
NG
OK
Change IC801
Check Q802, Q803 PIN5, 6, 7, 8 have the output of square wave at short time.
NG
OK
Check Q801, Q804, Q811, Q812, Q802, Q803
Check the output of T801, T802
Check connecter & lamp
OK
NG
Change T801, T802
To Next Page
