1-3
ASUS LCD Monitor VY2
79
Series
1.5 Connect cables
1.5.1 Rear of the LCD monitor
HDMI VGA
2
4
31
5
1. AC-IN Port
2. HDMI Port
3. VGA Port
4. Earphone-out Port
5. Kensington Lock

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus VY279HE-W and is the answer not in the manual?

Asus VY279HE-W Specifications

General IconGeneral
Panel Size27” W
Max. Resolution1920x1080@75Hz
Brightness (Typ.)250cd/m2
Intrinsic Contrast Ratio (Typ.)1000:1
Viewing Angle (CR>10)178°(H) /178°(V)
Display Colors16.7 M
Response Time1ms MPRT with Motion Sync On / 5ms GtG
Sound from HDMIYes
Audio Line-inNo
HDMI inputYes
D-Sub inputYes
DisplayPortNo
Power ON Consumption<17.8w (Mesauring a screen brightness of 200 nits Without audio / USB / Card reader connection)
Power saving mode< 0.5W
Power off mode< 0.5W
Voltage RatingAC 100~240V(Built-in)
Note*Based on Energy Star 7.0 standard
Chassis ColorsBlack
Tilt-5° ~ +23°
VESA Wall MountingYes (100mm x 100mm)
Temperature(operation)0℃~40℃
Weight and Dimensions IconWeight and Dimensions
Phys. Dimension with stand (WxHxD)613.34 x 435.60 x 201.70 mm
Phys. Dimension without stand (WxHxD) (For VESA Wall Mount)613.34 x 365.31 x 50.03 mm
Box Dimension (WxHxD)679 x 445 x 148 mm
Net Weight (Esti.)4.21 kg
Gross Weight (Esti.)6.8 kg
