Asus WL-330N3G User Manual

4-6 Chapter 4: Configuration
2. Specify a network name or SSID (Service Set Identier), which is a unique
identier attached to packets sent over WLAN.
3. Select a security level to enable encryption methods:
Low (None)
Medium (WEP-64bits)
Medium (WEP-128 bits)
High (WPA-PSK)
4. Select WAN Connection Type from the drop-down list. You are required to
enter the user name and password if you are using PPPoE, PPTP, or L2TP
connection. Contact your Internet Service Provider (ISP) for the user name
and password.
5. Click Apply to save the settings.
For more details on setting up the advanced functions, refer to the section 4.3
Advanced Setting.
After setting the ASUS WL-330N3G in Router mode, you need to connect the
WL-330N3G’s LAN port to an ADSL modem and connect your computer to
WL-330N3G’s SSID via wireless connection.
4.2.2 Access Point (AP) mode
In the Access Point (AP) mode, you can connect the Ethernet port and your
wireless devices into the same local area network (LAN).
Wireless computer
WL-330N3G
To congure the ASUS WL-330N3G in Access Point/AP mode:
1. Click the Access Point tab. The Access Point page appears.
