Asus WL-520gU User Manual

41
Chapter 6: Troubleshooting WL-520GU
Problem Action
If the ADSL “LINK” light
blinks continuously or
stays off, Internet access
is not possible - the Router
is unable to establish a
connection with the ADSL
network.
• Ensure that all your cables are all properly
connected .
• Disconnect the power cord from the ADSL
or cable modem, wait a few minutes, then
reconnect the cord.
• If the ADSL light continues to blink or stays
OFF, contact your ADSL service provider.
Network name or encryption
keys are forgotten
• Try setting up the wired connection and
conguring the wireless encryption again.
• Press the Restore button at the rear panel
of the wireless router for more than ve
seconds.
How to restore the system
to its default settings
• Press the Restore button at the rear panel
of the wireless router for more than ve
seconds.
• Refer to the section Firmware Restoration
in Chapter 5 of this user manual.
The following are the factory default settings:
User Name: admin
Password: admin
Enable DHCP: Yes (if WAN cable is plugged in)
IP address: 192.168.1.1
Domain Name: (Blank)
Subnet Mask: 255.255.255.0
DNS Server 1: 192.168.1.1
DNS Server 2: (Blank)
SSID: default

Asus WL-520gU Specifications

General

Bandwidth	2.4 GHz
xDSL connection	No
Dimensions (WxDxH)	164 x 116.5 x 31 mm
Power requirements	+5V; 2A
USB ports quantity	1
Filtering description	URL
Maximum data transfer rate	0.125 Gbit/s
Compatible operating systems	Windows 2000/XP/Vista
Full duplex	Yes
VPN support	IPSec, PPTP, L2TP
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.1x, IEEE 802.3, IEEE 802.3u
Channels quantity	13 channels
Ethernet LAN (RJ-45) ports	4
Security algorithms	WPA, WPA-PSK, WPA2
Authentication method	802.1x RADIUS, MAC
Storage temperature (T-T)	-30 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	20 - 90 %
Operating relative humidity (H-H)	50 - 90 %
LED indicators	LAN, WAN

Weight and Dimensions

Weight	262 g
