Asus ZenWiFi AX XT8 User Manual

151
Safety Notices
• Use this product in environments with ambient temperatures between 0°C(32°F) and 40°C(104°F).
• Refertotheratinglabelonthebottomofyourproductandensureyourpoweradaptercomplieswiththis
rating.
• DONOTplaceonunevenorunstableworksurfaces.Seekservicingifthecasinghasbeendamaged.
• DONOTplaceordropobjectsontopanddonotshoveanyforeignobjectsintotheproduct.
• DONOTexposetoorusenearliquids,rain,ormoisture.DONOTusethemodemduringelectricalstorms.
• DONOTcovertheventsontheproducttopreventthesystemfromgettingoverheated.
• DONOTusedamagedpowercords,accessories,orotherperipherals.
• IftheAdapterisbroken,donottrytoxitbyyourself.Contactaqualiedservicetechnicianoryourretailer.
• Topreventelectricalshockhazard,disconnectthepowercablefromtheelectricaloutletbeforerelocating
the system.
CE statement
Simplied EU Declaration of Conformity
ASUSTek Computer Inc. hereby declares that this device is in compliance with the essential requirements
andotherrelevantprovisionsofDirective2014/53/EU.FulltextofEUdeclarationofconformityisavailableat
https://www.asus.com/ca-en/Networking/ZenWiFi XT8/HelpDesk_Declaration/.
Declaration of Conformity for Ecodesign directive 2009/125/EC
Testing for eco-design requirements according to (EC) No 1275/2008 and (EU) No 801/2013 has been
conducted. When the device is in Networked Standby Mode, its I/O and network interface are in sleep mode
and may not work properly. To wake up the device, press the Wi-Fi on/o, LED on/o, reset, or WPS button.
ThisequipmentcomplieswithEUradiationexposurelimitssetforthforanuncontrolledenvironment.This
equipment should be installed and operated with minimum distance 20 cm between the radiator & your body.
All operational modes:
2.4GHz:802.11b,802.11g,802.11n(HT20),802.11n(HT40),802.11ac(VHT20),802.11ac(VHT40),802.11ax(HE20),
802.11ax(HE40)
5GHz:802.11a,802.11n(HT20),802.11n(HT40),802.11ac(VHT20),802.11ac(VHT40),802.11ac(VHT80),
802.11ac(VHT160),802.11ax(HE20),802.11ax(HE40),802.11ax(HE80),802.11ax(HE160)
Thefrequency,channelandthemaximumtransmittedpowerinEUarelistedbelow:
2400-2483.5MHz (1-13): OFDM: 19.9dBm(97.7mW); CCK: 17.9dBm(61.7mW)
5150-5250MHz (36-48): 22.9dBm(195mW)
5250-5350MHz (52-64): 22.9dBm(195mW)
5470-5725MHz (100-140): 29.9dBm(977mW)
The device is restricted to indoor use only when operating in the 5150 to 5350 MHz frequency range.
The adapter shall be installed near the equipment and shall be easily accessible.
English
AT BE BG CZ DK EE FR
DE IS IE IT EL ES CY
LV LI LT LU HU MT NL
NO PL PT RO SI SK TR
FI SE CH UK HR UA

Asus ZenWiFi AX XT8 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Modulation	1024-QAM
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	6600 Mbit/s
VPN support	IPSec, PPTP, L2TP, PPTP, OpenVPN
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
NAT functionality	PPTP, L2TP, IPSec, RTSP, H.323, SIP, PPPoE
Security algorithms	WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK
Product type	Tabletop router
Product color	Black
LED indicators	Power
Antennas quantity	6
Flash memory	256 MB
Internal memory	512 MB
Processor cores	4
Processor frequency	1500 MHz
Output current	1.75 A
Output voltage	19 V
AC input voltage	110 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	75 mm
Width	160 mm
Height	161.5 mm
Weight	716 g
