7
FAQ
FREQUENTLY ASKED QUESTIONS
Q1:
Does the AiMesh router support Access Point mode?
A: Yes. You can choose to set the AiMesh router as router mode or access
point mode. Please go to web GUI (http://router.asus.com), and go to the
page Administration > Operation Mode.
Could I setup wired connection between AiMesh routers (Ethernet backhaul)?
Q2:
A: Yes. AiMesh system supports both wireless and wired connection
between AiMesh router and node to maximize throughput and stability.
AiMesh analyzes the wireless signal strength for each frequency band
available, and then determines automatically whether a wireless or wired
connection is best to serve as the inter-router connection backbone.
1
Follow the setup steps to establish a connection between the AiMesh
router and node via Wi-Fi first.
2
Place the node in the ideal locations for best coverage. Run an Ethernet
cable from the LAN port of the AiMesh router to the WAN port of AiMesh
node.
3
AiMesh system will auto-select the best path for data transmission,
whether wired or wireless.
LAN-WAN
Modem
English

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus ZenWiFi AX XT8 and is the answer not in the manual?

Asus ZenWiFi AX XT8 Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
WAN connection typeRJ-45
Modulation1024-QAM
Wi-Fi bandTri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standardWi-Fi 6 (802.11ax)
WLAN data transfer rate (max)6600 Mbit/s
VPN supportIPSec, PPTP, L2TP, PPTP, OpenVPN
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Ethernet LAN (RJ-45) ports3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
NAT functionalityPPTP, L2TP, IPSec, RTSP, H.323, SIP, PPPoE
Security algorithmsWPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK
Product typeTabletop router
Product colorBlack
LED indicatorsPower
Antennas quantity6
Flash memory256 MB
Internal memory512 MB
Processor cores4
Processor frequency1500 MHz
Output current1.75 A
Output voltage19 V
AC input voltage110 - 240 V
Power source typeAC
AC input frequency50 - 60 Hz
Mac operating systems supportedMac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Windows operating systems supportedWindows 10, Windows 7, Windows 8, Windows 8.1
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth75 mm
Width160 mm
Height161.5 mm
Weight716 g
