Asus ZenWiFi AX XT8 User Manual

3
1
Plug the adapter into the DC-IN port, and press the power button.
2
The power LED will light up when your hardware is ready.
Hardware Explanations
Button and Port Explanations
2.5G / 1G WAN port
Connect your optical modem to this port with a network cable.
LAN ports 1-3
Connect your PC to a LAN port with a network cable.
Power buttonDC-IN port
2.5G / 1G
WAN port
LAN ports 1-3 USB 3.0/2.0 port
DC Power adapter DC Output: +19V with max 1.75A current
Operating Temperature 0~40
o
C Storage 0~70
o
C
Operating Humidity 50~90% Storage 20~90%
Specications:
English

Asus ZenWiFi AX XT8 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Modulation	1024-QAM
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	6600 Mbit/s
VPN support	IPSec, PPTP, L2TP, PPTP, OpenVPN
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
NAT functionality	PPTP, L2TP, IPSec, RTSP, H.323, SIP, PPPoE
Security algorithms	WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK
Product type	Tabletop router
Product color	Black
LED indicators	Power
Antennas quantity	6
Flash memory	256 MB
Internal memory	512 MB
Processor cores	4
Processor frequency	1500 MHz
Output current	1.75 A
Output voltage	19 V
AC input voltage	110 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	75 mm
Width	160 mm
Height	161.5 mm
Weight	716 g
