Asus ZenWiFi AX User Manual

113
MAC OS
1. Click the Apple icon
located on the top left of
your screen.
2. Click System
Preferences > Network
> Congure...
3. From the TCP/IP tab,
select Using DHCP in
the Congure IPv4
dropdown list.
4. Click Apply Now when
done.
NOTE: Refer to your operating system’s help and support feature for
details on conguring your computer’s TCP/IP settings.
C. Disable the dial-up connection, if enabled.
Windows
®
1. Click Start > Internet Explorer
to launch the browser.
2. Click Tools > Internet options >
Connections tab.
3. Tick Never dial a connection.
4. Click OK when done.
NOTE: Refer to your browser's help feature for details on disabling the
dial-up connection.

Asus ZenWiFi AX Specifications

General

WiFi Standard	Wi-Fi 6 (802.11ax)
MU-MIMO	Yes
RAM	512 MB
Flash	256 MB
Mesh Networking	Yes
OFDMA	Yes
Frequency Bands	2.4 GHz, 5 GHz
Coverage	Up to 5500 sq. ft.
Ports	1 x Gigabit WAN port
Beamforming	Yes
