Asus ZenWiFi AX User Manual

7
1.3 Your wireless router
1
Plug the adapter into the DCIN port, and press the power
button.
2
The power LED will light up when your hardware is ready.
Button and Port Explanations
2.5G / 1G WAN port
Connect your optical modem to this port with a network cable.
LAN ports 1-3
Connect your PC to a LAN port with a network cable.
Power buttonDCIN port LAN ports 1-3 USB 3.0/2.0 port
DC Power adapter DC Output: +19V with max 1.75A current
Operating Temperature 0~40
o
C Storage 0~70
o
C
Operating Humidity 50~90% Storage 20~90%
Specications:
2.5G / 1G
WAN port

Asus ZenWiFi AX Specifications

General

WiFi Standard	Wi-Fi 6 (802.11ax)
MU-MIMO	Yes
RAM	512 MB
Flash	256 MB
Mesh Networking	Yes
OFDMA	Yes
Frequency Bands	2.4 GHz, 5 GHz
Coverage	Up to 5500 sq. ft.
Ports	1 x Gigabit WAN port
Beamforming	Yes
