5.2 Firmware Restoration
Firmware Restoration is used on an ASUS Wireless Router that
failed during its rmware upgrading process. It uploads the
rmware that you specify. The process takes about three to four
minutes.
IMPORTANT: Launch the rescue mode on the router before using the
Firmware Restoration utility.
NOTE: This feature is not supported on MAC OS.
To launch the rescue mode and use the Firmware Restoration
utility:
1. Unplug the wireless router from the power source.
2. Hold the Reset button at the rear panel and simultaneously
replug the wireless router into the power source. Release the
Reset button when the Power LED at the front panel ashes
slowly, which indicates that the wireless router is in the rescue
mode.

Asus ZenWiFi AX Specifications

General

WiFi Standard	Wi-Fi 6 (802.11ax)
MU-MIMO	Yes
RAM	512 MB
Flash	256 MB
Mesh Networking	Yes
OFDMA	Yes
Frequency Bands	2.4 GHz, 5 GHz
Coverage	Up to 5500 sq. ft.
Ports	1 x Gigabit WAN port
Beamforming	Yes
