Asus ZenWiFi AX User Manual

33
Time Scheduling
Time Scheduling allows you to set the time limit for a client’s
network usage.
NOTE: Ensure that your system time is synchronized with the NTP
server.
To congure Time Scheduling:
1. From the navigation panel, go to General >AiProtection >
Parental Controls > Time Scheduling.
2. From the Enable Time Scheduling pane, click ON.
3. From the Clients Name column, select or key in the client’s
name from the drop down list box.
NOTE: You may also key in the client’s MAC address in the Client
MAC Address column. Ensure that the client name does not contain
special characters or spaces as these may cause the router to function
abnormally.
4. Click to add the client’s prole.
5. Click Apply to save the settings.

Asus ZenWiFi AX Specifications

General

WiFi Standard	Wi-Fi 6 (802.11ax)
MU-MIMO	Yes
RAM	512 MB
Flash	256 MB
Mesh Networking	Yes
OFDMA	Yes
Frequency Bands	2.4 GHz, 5 GHz
Coverage	Up to 5500 sq. ft.
Ports	1 x Gigabit WAN port
Beamforming	Yes
