10. You may now remove the tail pipes by sliding them
forward within the chassis, then out. (fig, 12-14).
Installation
1. To install the exhaust system, reverse the removal
procedure.
Air Cleaner
Removal
1. Remove the cover and the filter elements from the
air cleaner assembly. (fig. 12-15)
2. Loosen the clamp securing the intake hose to the
air cleaner housing. (fig. 12-16)
3. Remove the bolts and nuts securing the air cleaner
housing to the chassis. (fig. 12-17)
12-4
Rubber Track Loader
12. Engine
12-14
Required Tools
Combination Wrenches
Socket Wrench & Extension
12-15
12-16
12-17
