AT BS5 - Overview

BS5 User Manual v2.0 Introduction  5
Overview
Figure 1. BS5 sensor overview
Earthing Point
Mounting
Holes
6.75mm dia.
Cable Strain
Relief
Output Range
DIP Switches
See fig. 4 for
more detail
Measurement
Range DIP
Switches
Weatherproof
Enclosure
Wiring
Terminal
Sun Shield /
Bracket
