AT BS5 - Operation for DL2 e; Sensor Set-up

12  Instructions BS5 User Manual v2.0
Operation for DL2e
Wiring Diagram
Use a LAC1 15 channel card inside the logger
Logger
Cable
Sensor
CH1+
White/Clear
ANG OUT
CH1-
Green
ANG GND
CH61- or
CH62-
Black
GROUND
CH61- or
CH62-
Screen (white
and black)
N/A
CH63
N/O
Red
+12V IN
See Climatronics User Manual figure 3.4 ANALOG WIRING
Sensor Set-up
SW1 analogue output switch setting
Range
SW1-1
SW1-2
0-2000mV
ON
OFF
Table 5. See also Climatronics User Manual section 5.0 USER
INTERFACE
Strip back approximately 150mm of the cable insulation to allow for wiring
into any channel of the DL2e.
