BS5 User Manual v2.0 Instructions  9
Operation for GP1
Wiring Diagram
Logger
Cable
Sensor
CH+
White/Clear
ANG OUT
CH -
Green
ANG GND
CH GND
Black
GROUND
CH GND
Screen (white
and black)
N/A
CH PWR
Red
+12V IN
See Climatronics User Manual
Sensor Set-up
SW1 analogue output switch setting
Range
SW1-1
SW1-2
0-2500mV
OFF
ON
Table 3. See Climatronics User Manual section 5.0 USER INTERFACE
