8  Instructions BS5 User Manual v2.0
ANALOG OUT
SW1-1
SW1-2
0-1000mV
ON
ON
0-2000mV
ON
OFF
0-2500mV
OFF
ON
Table 1. SW1 Analogue output selector
Four DIP switches provide the option of 16 pressure ranges, the largest
being 600-1100mbar. This enables the user to measure pressure at most
altitudes.
Lower
Limit
Upper
Limit
SW2-1
SW2-2
SW2-3
SW2-4
600
800
ON
ON
ON
ON
600
900
OFF
ON
ON
ON
600
1000
ON
OFF
ON
ON
600
1100
OFF
OFF
ON
ON
700
800
ON
ON
OFF
ON
700
900
OFF
ON
OFF
ON
700
1000
ON
OFF
OFF
ON
700
1100
OFF
OFF
OFF
ON
800
800
ON
ON
ON
OFF
800
900
OFF
ON
ON
OFF
800
1000
ON
OFF
ON
OFF
800
1100
OFF
OFF
ON
OFF
900
800
ON
ON
OFF
OFF
900
900
OFF
ON
OFF
OFF
900
1000
ON
OFF
OFF
OFF
900
1100
OFF
OFF
OFF
OFF
Table 2. SW2 Pressure range selector
See Climatronics User Manual section 5.0 USER INTERFACE for a
comprehensive table.
