GB 14
The oven has an high-performance air circulation system which gives re-
markable results for cooking and cleaning, as long as the following points
are applied:
•
The oven may be fitted either underneath a work surface or in a suitable
sized column unit. Cut a hole measuring 50 mm x 50 mm in the back wall of
the insert space for the electric cable to pass through (See diagram, left).
•
Centre the oven in the unit, and make that it is at least 2 mm from any
other unit beside it.
•
The unit must be heat-resistant (or covered with heat-resistant material).
•
The oven must be disconnected from the power supply while it is being
installed in the unit.
•
For greater stability, fix the oven in the unit with 2 screws in the holes on
the side uprights (see diagram). Make a 3 mm diameter hole in the side
of the unit first to prevent the wood from splitting.
installer's information
housing
