7
Wall-mount installation (optional)
Pull the integrated wall-mount bracket and release it from the tabletop
orientation. Rotate it down into wall-mount position and then push it into
the telephone base until it clicks into place.
2
3
Slide the handset tab upward. Rotate the handset tab by 180 degrees. The
protruding edge of the handset tab holds the corded handset in place when
the telephone is mounted on the wall.
Make sure the telephone line cord and the power adapter are plugged into
their jacks on the telephone base, and are routed through the channels.
Plug the power adapter and telephone line into the wall outlets.
Align the mounting studs on the mounting plate with the mounting holes on
the bracket and press the telephone base down until it clicks securely into
place.
Handset tab
Switch hook
