Telephone installation
Telephone base installation
Install the mounting bracket for tabletop use.
Option 1: To install your telephone in a low tabletop position, insert the fixed
tabs of the mounting bracket into slots
a
and
b
. Press the flexible tabs
A
and
B
into slots
c
and
d
until they click into place.
1.
A
B
A B
c
Option 1: Low tabletop position
Option 2: To install your telephone in a high tabletop position, insert the fixed
tabs of the mounting bracket into slots
c
and
d
. Press the flexible tabs
A
and
B
into slots
a
and
b
until they click into place.
A
A
Option 2: High tabletop position
c
