17
Figure 5: Terminal box with fastening screw c
Figure 6: Terminal box with grub screw c
>
Then tighten the fastening components to the relevant torque, see the
following table.
Table 4: Torque values for 8.8-type screws
Thread size
Torque
M5
6 Nm
M6 10 Nm
M8 25 Nm
M10 49 Nm
M12 85 Nm
M16 210 Nm
M20 425 Nm
