PE6108AV / PE6208AV / PE8208AV User Manual
40
Delay Time (sec)
Power ON
Sets the amount of time the eco PDU waits after the Power Button
is clicked (see Outlet Status (PE6208AV), page 32), before it turns
on the power to the outlet. You must check the Enable Power On
Time Schedule Setting box for this setting to take effect.
See Power On Time Schedule Settings, page 34, for details.
Note: The default delay time is 0 seconds; the maximum is 999
seconds. When a series of outlets are scheduled to be powered
up, they turn on in sequence with a default delay of 10
milliseconds between each outlet.
Delay Time (sec)
Power OFF
Sets the amount of time the eco PDU waits after the Power Button
is clicked (see Outlet Status (PE6208AV), page 32), before it turns
off the power to the outlet.
For the System after AC Back option (see below), after the delay
time expires, the eco PDU waits another fifteen seconds, then
shuts the computer down.
The default delay time is 15 seconds. The maximum delay time is
999 seconds.
Remote Turn ON
Method
Use the drop-down menu to select one of the choices, below:
Wake on LAN: This is a Safe Shutdown and Restart option. If this
is selected, when an Outlet is turned Off, the eco PDU first sends
a message to the computer telling it to prepare for a shutdown; it
then waits for the amount time set in the Power Off Delay field to
give the OS time to close down before the computer is powered
down to standby mode.
Likewise, when the Outlet is turned On, the eco PDU waits for
the amount time set in the Power On Delay field, then sends an
Ethernet message to the computer connected to the Outlet
telling the computer to turn itself On.
Note: For Safe Shutdown and Restart, the computer must be
running Windows (98 or higher), or Linux, and the Safe
Shutdown program (available by download from our website),
must be installed and running on the computer.
System after AC Back: This is a Safe Shutdown and Restart
option. If this is selected, when an Outlet is turned Off, the eco
PDU first sends a message to the computer telling it to prepare
for a shutdown; it then waits for the amount time set in the Power
Off Delay field to give the OS time to close down before the
computer is powered down.
When the Outlet is turned On, the eco PDU waits for the amount
time set in the Power On Delay field, then sends power to the
server. When the server receives the power, it turns itself on.
Note: For Safe Shutdown and Reboot, the computer must be
running Windows (98 or higher), or Linux, and the Safe
Shutdown program (available by download from our website),
must be installed and running on the computer.
Kill the Power: If this option is selected, the eco PDU waits for the
amount time set in the Power Off Delay field, and then turns the
Outlet's power Off. Turning the power off performs a cold (non-
safe) shutdown.
Heading Meaning
