SIGNO
Fiat
Doblo 10/2001–
SIGNO
Fiat
Doblo 10/2001–
C
A
B
Grundträger 1. Bügel/ basic carrier 1st carrier bow = Position A
Grundträger 2. Bügel/ basic carrier 2nd carrier bow) = Position B oder/or C
CAB
®
Position A:
Lange Version
Long version
®
Position B/C:
Kurze Version
Short version
3
ca. 2 x
5
FL
FR
A1 = A2
FL FR
A2A1
ca. 902 mm ✔
(RL)
(RR)
C1 = C2
(RL) (RR)
C2C1
ca. 854 mm ✔
RL
RR
B1 = B2
RL RR
B2B1
ca. 885 mm ✔
4
4 - 6 Nm
✔
FL=Nr.093313
FR=Nr.093314
RL=Nr.093315
RR=Nr.093315
6
ca. 6 Nm
7
1
®
2
