11
Specifications
 120/240 V ± 10% to ± 15%, 50-60 Hz
 Less than 5 VA
 Analog-Single turn potentiometer 270° rotation
 0.2% span
 Temperature: Deviation meter ±50°F or ±30°C of setpoint
Load: Red LED output light
Alarm: Red LED
 ±0.5% of span at calibration points
 Automatic, electrical
 ±0.3% of span
 Failsafe, open sensor, output zero,
 Upscale indication on meter
 J,K,R,T, thermocouples, Platinum RTD DIN standard
 Thermocouple, maximum lead resistance
 100Ω for specied accuracy
 On/o󰀨 or nominal 5°F to 50°F (3°C to 30°C)
 Adjustable over 100% of proportional band
 0.5 to 40 sec
 0.7, 1, 2 or 4 min via internal switches
 Maximum error ±1°C with 240 V, 60 Hz applied
 As a common mode signal between sensor input and chassis ground

Maximum error = 1°C with series mode signal of 100 mV pk-to-pk at 60 Hz
 32°F to 131°F (0°C to 55°C)
 Front Panel - 3.780 sq. in. (96 mm
2
), Depth Behind Panel - 3.780˝
(96 mm), Panel cutout - 3.622 sq. in. (92 mm
2
)
STANDARD RANGE CODE
Thermocouple
Code Set Range Type
14F -100 to +400°F T
03F 0 to +300°F J
04F 0 to +400°F J
13F -100 to +350°F J
16F 100 to +600°F J
08F 0 to +800°F J
01F 0 to 1000°F J
03C 0 to +300°C J
05C 0 to 500°C J
51F 500 to +1500°F K
02F 0 to +2000°F K
25F 0 to +2500°F K
01C 0 to +1000°C K
30F 0 to 3000°F R
Platinum RTD (3-wire, 100Ω @ 0°C)
R30 0 to 300°F
R60 0 to 600°F
R10 0 to 1000°F
R06 0 to 600°C
Control Options Code
O = Proportional
(Standard)
A = 3-mode (PID)
Alarms
B = High deviation alarm only*
C = Low deviation alarm only*
D = High and low deviation alarm*
E = Full scale process alarm*
Sensor Input Code
0 = Thermocouple
2 = RTD
Special Options
000 = None
Consult factory for
available special
options you may need
for your application.
Output type (Plug-In) Code
B = SPDT Relay, 7 A/5 A
F = 4-20 mAdc
S = Pulsed 20 Vdc
T = SPST SS Relay, 1 A
L = Limit Control*
2 0 0 - - - -
Ordering
Codes
