Introduction
Precautions
Congratulations on your purchase of an Athena® Series 2000 analog temperature controller. It is a U.L.
listed, 1/4-DIN controller for use in a variety of applications. Standard features include time proportioning
with auto-adjusting cycle time, adjustable bandwidth (for on-off to wide band proportioning), and offset
(manual reset). Outputs include relay, triac, or mAdc types.
If you have questions or require any assistance with your controller or with any temperature control problem,
please contact your Athena representative.
After unpacking, inspect the instrument for any physical damage that may have occurred in shipping. Save
all packing materials and report any damage to the carrier immediately.
Locating
Select a location for the controller where it will not be subject- ed to excessive shock, vibration, dirt, moisture
or oil. The ambient temperature of the area should be between 30° and 130° F. (Dust, oil, water resistant
cover is available to protect from harsh environments. Contact factory for details.)
Safety Warning
In addition to presenting a potential fire hazard, high voltage and high temperature can damage equipment and
cause severe injury or death. When installing or using this instrument, follow all instructions carefully and use
approved safety controls. Electrical connections and wiring should be performed only by suitably trained personnel.
Do not locate this instrument where it is subject to excessive shock, vibration, dirt, moisture, oil, or other liquids. The
safe operating temperature range for this unit is 32°F to 140°F (0°C to 60°C).
This unit has been tested and found to be compliant with “NEMA Type 4X Enclosure - For Indoor Use Only.” When
properly installed, this controller will maintain the integrity of a NEMA enclosure and remain “Watertight.” This rating
is only applicable when the controller is properly installed into a suitably rated NEMA Type 4X housing.
Approvals
E66598 Temperature Indicating and
Regulating Equipment.
E66598 Temperature Indicating and
Regulating Equipment.
