Safety
Warning
In addition to presenting a potential fire hazard, high voltage
and high temperature can damage equipment and cause
severe injury or death. When installing or using this instru-
ment, follow all instructions carefully and use approved
safety controls. Electrical connections and wiring should be
performed only by suitably trained personnel.
Do not locate this instrument where it is subject to excessive
shock, vibration, dirt, moisture, oil or other liquids.
Safe ambient operating temperature range is 32° to 131° F
(0° to 55° C).
NOTES ON CE EMC COMPLIANCE
This unit is compliant with the
following standards when properly
installed in a grounded metal panel:
EN55011 (CISPR 11), Class B
ENS0082-1
Introduction
Precautions
Congratulations on your purchase of an Athena
®
Series 16
Single-Loop Controller. It is designed for ease of use and
reliability wherever accurate closed-loop control is required.
Your Series 16 has been configured according to your order-
ing specifications as either a universal process controller or
a dedicated temperature controller. In addition, special func-
tions such as a heater break alarm, digital communications,
etc., do not require you to make any internal jumper or DIP
switch settings.
After following the instructions for installation, simply step
through and set your desired parameters using the Series
16’s easy menu system. The instrument may then be auto-
matically or manually tuned to your process for optimum
setpoint control. A Quick-Start Reference Card is attached to
the back of the instruction manual for experienced users of
PID controllers. If you still have questions or require any
assistance in setting up or operating your controller, please
contact your Athena representative or call 1-800-782-6776.
After unpacking, inspect the instrument for any physical
damage that may have occurred in shipping. Save all packing
materials and report any damage to the carrier immediately.
