Athena SERIES 16 User Manual

Table of Contents
Installation
Mounting 1
Wiring 2
Operation
Notes on Outputs 4
Parameter Menu Organization 6
Notes on Alarms 10
Tuning 17
Special Functions
Auto/Manual 22
Remote Setpoint Select 22
Process Variable Retransmission 24
Heater Break Alarm 25
Transducer Excitation 26
Digital Communications 27
Recalibration Procedure 34
Error Codes 34
Warranty/Repair Information 35
Technical Specifications 36
Ordering Codes 39

Athena SERIES 16 Specifications

General

Output	Relay
Input	Analog
Power Supply	24V DC
Input Voltage	100-240 VAC
Communication Ports	RS-485
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C to 70°C
