ATI Technologies Q46 Communications Manual

ATI Q46 Ethernet/IP Communications Manual
15
1.9 Ethernet/IP Data Files
The data organization shown in section 1.6 corresponds to the same mapping as
all the other communication interfaces on the Q46. All Q46 instruments provide
20 bytes of input data to the master, and the meaning of the bytes changes
slightly depending on which Q46 instrument is used.
Byte
Data Type
Sensor
Description
Data Format
1 to 4
long(32)
Main
Measured Main
See Figure 11
5 to 8
long(32)
Main
Measured
Temperature
25.00° C = 2500
9 to 12
long(32)
Aux1
Measured Aux1
See Figure 11
13 to 16
long(32)
Aux2
Measured Aux2
See Figure 11
17
Char(8)
NA
System Status 1
(binary) 00000000
18
Char(8)
NA
System Status 2
(binary) 00000000
19
Char(8)
NA
Alarm Status
(binary) 00000000
20
Char(8)
NA
Instrument ID
See Figure 11
Figure 9 - Q46 Ethernet/IP Register Data Format
Figure 10 – Base Status Register Bitfield Flags
Byte
Bitfield
Description
17
0 (lsb)
Raw Hi
1
17
1
Raw Lo
1
17
2
Main Hi
17
3
Main Lo
17
4
Temp Hi
17
5
Temp Lo
17
6
Aux1 Hi
2
17
7
Aux1 Lo
18
0
NU
18
1
NU
18
2
LCD Controller Fail
18
3
Cal Main Fail
18
4
PID Controller Fail
18
5
Cal TC Fail
18
6
TC Error
18
7
Acknowledge Fail (global)
19
0
Alarm 1, Relay A
19
1
Alarm 2, Relay B
19
2
Alarm 3, Relay C
19
3
Alarm 4, Relay D (optional)
19
4
Alarm 5, Relay E (optional)
19
5
Alarm 6, Relay F (optional)
19
6
NU
19
7
NU
