ATI Technologies Q46 Communications Manual

ATI Q46 Ethernet/IP Communications Manual
16
Figure 11 – Parameter Specific Data Formats
1
Raw Hi/Lo is an internal sensor flag signal that indicates the raw signal is measuring too high or low,
and can indicate sensor service is required or it may simply mean the sensor is presently out of the
process liquid. This signal does not apply to the Q46T/C2/C4/CT.
2
This bit flag is the glass break diagnostic for pH.
3
For Conductivity units, concentration data shows for concentration instruments, and TDS shows for
standard conductivity units (not both.)
Instrument
Main
Aux1
Aux2
Main Data
Format
Aux1 Data
Format
Aux2 Data
Format
Q46H/62/63
/79PR
ID=41
Chlorine
pH
PID
14920=
1.4920 ppm
700=
7.00pH
475=
47.5%
Q46S/66
ID=81
Sulfite
None
PID
14920=
1.4920 ppm
None
475=
47.5%
Q46S/81
ID=81
Sulfide
None
PID
14920=
1.4920 ppm
None
475=
47.5%
Q46H/64
ID=41
Ozone
pH
PID
14920=
1.4920 ppm
700=
7.00pH
475=
47.5%
Q46H/65
ID=41
Chlor Diox
pH
PID
14920=
1.4920 ppm
700=
7.00pH
475=
47.5%
Q46D
ID=49
D.O.
Sat
PID
840=
8.40 ppm
980=
98.0% sat
475=
47.5%
Q46P
ID=53
pH
None
PID
700=
7.00 pH
None
475=
47.5%
Q46R
ID=57
ORP
None
PID
-137=
-137 mV
None
475=
47.5%
Q46N
ID=45
Total Amm
Mono
Chloramine
Free
Amm
100=
1.00 ppm
51=
0.51 ppm
321=
3.21 ppm
Q46C2
ID=69
Conductivity
3
Concentration
3
TDS
100123=
100.123 uS
13=
1.3%
2235=
223.5 mg/L
Q46C4
ID=65
Conductivity
3
Concentration
3
TDS
2238=
2.238 mS
13=
1.3%
2235=
223.5 mg/L
Q46CT
ID=61
Conductivity
3
Concentration
3
TDS
2238=
2.238 mS
13=
1.3%
2235=
223.5 mg/L
Q46F
ID=73
Fluoride
None
PID
1000=
1.000 ppm
None
475=
47.5%
Q46T
ID=85
Turbidity
None
PID
16=
0.16 NTU
None
475=
47.5%
