Using TV Out
6-3
Connecting to a TV or a VCR
To connect your RADEON 9700 Series card to a TV or
a VCR, use an S-Video cable. However, most TVs (and
VCRs) have a Composite video input, in which case you
can use the supplied S-Video-to-Composite video
adapter. If your TV has cable input only, you can
connect your graphics card to your TV through your
VCR or an RF modulator (available in most electronics
stores).
Connecting Your S-Video Out to a TV or VCR
1. Turn off your PC and your TV (or VCR).
2. Ensure your card was installed correctly as per the
Getting Started Guide.
3. Determine if your TV (or VCR) has a S-Video or
Composite video connection.
4. Looking at the back of your PC, locate your S-
Video Out. Using a S-Video cable or the supplied
adapter cable, attach one end of the cable to your
graphics card and the other to your TV (or VCR).
Refer to the illustration for further help.
5. Turn on your TV (or VCR) then your PC.
